21 - HIGH-VOLTAGE ELECTRICAL TESTING

TIYO specialist analyses high-voltage electrical tests on a computer
We use around 10 professional technologies
High-Voltage Electrical System Validation

Our laboratory conducts comprehensive high-voltage electrical testing with power supply capabilities up to 1.100 V/36 kW. Testing includes transient overvoltage/undervoltage evaluation, voltage and current ripple analysis, and various power failure scenarios. For control lines, we perform pulse testing, reset behavior verification, interruption response, and polarity reversal testing using specialized equipment including 4-quadrant NetWave 30 power supplies, automotive transient simulators, and load dump generators.

Advanced Measurement & Safety Features

We provide comprehensive measurement capabilities including insulation resistance, dielectric strength testing, and spectral impedance analysis. Our 48-channel DAQ system with 1 MS/s sampling rate enables detailed performance monitoring during tests. All testing incorporates active liquid cooling for devices under test, advanced safety protection systems, and optional climatic chamber integration. Testing complies with LV 123, WV 80300, and customer-specific standards with complete validation project management and in-depth analysis support.

SCOPE
Tests on power supply lines
  • Voltage range up to 1.100 V; up to 36 kW
  • Transient overvoltage/undervoltage
  • Voltage and current ripple
  • Other power fail tests
Tests on control lines
  • Pulses tests
  • Reset behaviour
  • Interruptions
  • Polarity reversal
  • Other fail tests
EQUIPMENT
  • Supply range up to 1100 V; up to 36 kW
  • 4-quadrant voltage power supply NetWave 30
  • Automotive power fail simulator (PFM 200N)
  • Ultra compact simulators for Automotive transients (UCS 200N50)
  • Capacitive coupling clamp for Automotive testing
  • Electronic switch BS 200N100
  • Artificial network AN 200N100; AN 2050
  • Mechanical switch BSM 200N40 (12/24 V DC/40 A)
  • Load dump generator (LD 200N100)
BENEFITS
  • Insulation resistance, dielectric strength
  • Spectral impedance measurement
  • Monitoring DAQ system up to 48 channels; sampling rate up to 1 MS/s
  • Deep analysis and customer support
  • Validation project management
  • Active cooling of DUT by liquid
  • Advanced online safety conditions (sample protection)
  • Climatic loading in chambers
STANDARDS
  • LV 123
  • WV 80300
  • Customer standards
